DJI Zenmuse L3 with Enterprise Care Plus - 1 Year Warranty Auto-Activated
DJI Zenmuse L3 with Enterprise Care Plus - 1 Year Warranty Auto-Activated
The DJI Zenmuse L3 is DJI’s first long-range, high-precision aerial LiDAR system. It redefines efficiency and accuracy for surveying, inspection, and 3D modeling professionals. Revolutionary Scope: Up to 950 meters on objects with low reflectivity (10%). Centimeter Accuracy: Achieves a vertical accuracy of 3 cm and a horizontal accuracy of 4 cm at an altitude of 120m. Superior Penetration: Up to 16 laser returns and an ultra-fine spot for detailed capture under vegetation. Fusion LiDAR + Dual 100MP Camera: Create photorealistic colorized point clouds and 2D/3D models in a single flight. Integrated ecosystem: Free and powerful processing with DJI Terra, and smart mission planning with DJI Pilot 2. Matrice 400 Exclusive: Paired with DJI Matrice 400, the L3 turns every flight into a powerhouse of data collection. Surveyors can capture high-density, survey-grade point clouds and photogrammetry-level imagery across vast areas up to 100 km² per day.
Description
The DJI Zenmuse L3 is DJI’s first long-range, high-precision aerial LiDAR system. It redefines efficiency and accuracy for surveying, inspection, and 3D modeling professionals.
- Revolutionary Scope: Up to 950 meters on objects with low reflectivity (10%).
- Centimeter Accuracy: Achieves a vertical accuracy of 3 cm and a horizontal accuracy of 4 cm at an altitude of 120m.
- Superior Penetration: Up to 16 laser returns and an ultra-fine spot for detailed capture under vegetation.
- Fusion LiDAR + Dual 100MP Camera: Create photorealistic colorized point clouds and 2D/3D models in a single flight.
- Integrated ecosystem: Free and powerful processing with DJI Terra, and smart mission planning with DJI Pilot 2.
Matrice 400 Exclusive: Paired with DJI Matrice 400, the L3 turns every flight into a powerhouse of data collection. Surveyors can capture high-density, survey-grade point clouds and photogrammetry-level imagery across vast areas up to 100 km² per day.
Documents
Specifications
- BrandDJI Enterprise
- Product TypeDrone Payload
- Camera24 MP
- Combined Horizontal FOV107°
- Gimbal3-Axis Stabilized Gimbal
- IP RatingIP54
- Laser Beam Divergence0.25 mrad (1/e²)
- Laser Spot Size41 mm@120 m (1/e²); 86 mm@300 m (1/e²)
- Laser Wavelength1535 nm
- Minimum Effective Detection Distance10 m
- Payload TypeLiDAR Mapping and Photogrammetry
- Photo Size6144×4096
- Point Cloud System AccuracyAt 120m Flight Altitude: Vertical Accuracy: 3 cm (RMSE) & Horizontal Accuracy: 4 cm (RMSE), At 300m Flight Altitude: Vertical Accuracy 5 cm (RMSE) & Horizontal Accuracy: 7.5 cm (RMSE)
- Point Cloud Thickness1.2 cm@1σ (120m nadir flight altitude); 2 cm@1σ (300m nadir flight altitude)
- Power64 W (typical), 100 W (max)
- Ranging AccuracyAbsolute Accuracy: ±10 mm; Repeatability: < 5 mm (1σ)
- RGB Ground Sampling DistanceAverage Value: 3 cm (300m nadir flight altitude)
- Supported AircraftDJI Matrice 400 (requires the Zenmuse L3 single gimbal connector)
- Weight1.60 kg (without single gimbal connector)
